SMT DIP LCP Soldering Micro USB Female Connector USB 3.0 Solder Connector 20Pin

Ask Lasest Price
Brand Name :	Jinze
Model Number :	DP08D-LBA4N-THA
Certification :	SGS/ROHS
Price :	Negotiation
Payment Terms :	T/T
Supply Ability :	80000pcs/ Day
Delivery Time :	15-25 Days

Add to Cart

Product Details
Company Profile

SMT DIP LCP Soldering Micro USB Female Connector USB 3.0 Solder Connector 20Pin

Specifications

Housing	LCP UL94V-0 Black
Terminal	Brass (C2680), T=0.20mm
Shield	C2680, T=0.40mm
Cover	LCP UL 94V-0 Black
Mylar	Polyimide
Terminal Finish	Au 1u" Plating on Contact Area
	Matte Tin 80u" plating on solder tail
	Under Nickel Plating 50u" Min Over All
Shield	50u" Min. Nickel underplated Overall
Current Rating	0.5A
Voltage Rating	40V
Contact Resistance	40mΩ Max
Insulation Resistance	Unmated 100mΩ Min
Dielectric Withstanding Voltage	500 V AC/1 Minute
Durabilty	10000 Cycles
Operation Temperature	-20°C~+85°C
Storage Temperature	-20°C~+65°C

Images:

SMT DIP LCP Soldering Micro USB Female Connector USB 3.0 Solder Connector 20Pin

Drawings:

SMT DIP LCP Soldering Micro USB Female Connector USB 3.0 Solder Connector 20Pin

DP08D-LBA4N-THA.pdf, if you need the Drawing, pls download it!

Features and Benefits

• PCB space saving footprint
• D-shaped chamfered interface provides polarization
• Fully shielded against EMI and RFI emissions
• Detent locks and latch holes for secure mating connection
• PCB alignment pegs
• PCB solder pegs for in creased rigidity and retention to PCB

Product Application Information

These DisplayPort receptacle connectors form part of the DisplayPort interconnection system which is used for delivering high definition video of up to 10.8 Gbit/s and audio signals. Applications include games consoles, monitors, personal computers, projectors, set-top boxes, TV displays and work stations

Is this socket protected against interference?

Yes, this socket is fully shielded for protection against EMI (electromagnetic interference) and RFI (radio frequency interference), so you can rest assured you'll get reliable signal transmission.
